How to use Carprog for Volvo 2000-2010 mileage change via OBD

Possible to use Carprog for Volvo dashboard emulator? Change km…

Yes. This is Carprog volvo S60 dashboard testing
carprog-volvo-change-km-1

carprog-volvo-change-km-2

carprog-volvo-change-km-3

carprog-volvo-change-km-4

carprog-volvo-change-km-5

carprog-volvo-change-km-6

carprog-volvo-change-km-7

carprog-volvo-change-km-8

carprog-volvo-change-km-9

carprog-volvo-change-km-10

carprog-volvo-change-km-11
Carprog and Volvo S60 details can be found at
Thanks to obdii365.com

You need:
CarProg Volvo odometer correction software
Additional cables are required – A1+ (A1 PLUS) ODB2 adapter and A21 VOLVO CAN cable.  These cables are included in the full package:

How to use Carprog for Volvo dashboard:
With this software you can Read/Write dashboard EEPROM memory by OBDII CAN diagnostic, Read/Write dashboard processor flash by OBDII CAN diagnostic, repair odometer, reset oil service and erase error memory.
Works with these cars:
  • Volvo S80 1999-2000 with HC08 1H56A micro;
  • Volvo S60, V70, S80 2000-2001 with HC912 4F73K micro;
  • Volvo S60, V70, S80, XC70, XC90 2001-2004 with HC912 3K91D micro;
Volvo S40, V40, S50, S60, V70, S80 2004-2007 with 9S12 0L85D micro (now only by dashboard connector); Use cable C1 and A1+ (no need VOLVO OBD adapter).
carprog-volvo-0l85d-wiring-1

carprog-volvo-0l85d-wiring-2

carprog-volvo-0l85d-wiring-3
  • Volvo V50 2007+ with 9S12 3L16Y micro;
  • Volvo S60, V70, XC60, XC70, XC90 2007+ with 9S12 1K78X micro;
HINT:
after first programming phase start car engine twice and only after push “OK” on CarProg(CarProg ask just switch ignition ON-OFF)
carprog-volvo-test-1

carprog-volvo-test-2

carprog-volvo-test-3

Tutorial: How to build a C1 adapter for Volvo km change:

WARNING:
If you use C1 together with A1MULTI – please cut OBDII male connector pins 3 and 11 like in picture:

A1MULTI adapter has 3 different CAN lines and this modification will disconnect CAN3-11 from CAN6-14 (look C1 schematic).
carprog-c1-cable-modification-1
Using this additional cable you can test car electronic on the table:
  • Volvo dashboard repairing on the table;
  • Airbag testing and “crash data erase” on-table;
  • Opel, VAG ECU programming on-table;
carprog-c1-cable-modification-2

carprog-c1-cable-modification-3

carprog-c1-cable-modification-4

Thanks to codecard.eu.
