Yanhua Mini ACDP Clone Benz W117 VGS2 FCDT: Confirmed

 Confirmed working: Yanhua Mini ACDP with Module 16 can clone Mercedes W117 VGS2 FCDT gearbox.

Image 3: Yanhua Mini ACDP Programmer with Module 16 for Benz Gearbox Clone and Renew



Here are the simple guide:

1. Hardware Connection

Note: Please confirm whether the gearbox module model is correct.

Step 1. Please prepare ACDP, OBP+ICP adapter, interface board and gearbox.



Step 2. Connect the interface board correctly to the gearbox interface as shown.

Step 3. Short the CAN resistor on the OBP+ICP adapter to the “CAN-R Join”.



Step 4. Connect ACDP, OBP+ICP adapter, interface board and gearbox.



2. Software operation guide:

Click on “Benz ” -> Gearbox clone/refresh -> A Class -> VGS2_FDCT -> function options (Identify, Full backup data, full write data, read INT Flash, read INT EEPROM, write INT FLASH, write INT EEPROM).



Related video: Yanhua Mini ACDP Benz 722.9 VGS2 VGS3 gearbox clone – obdii365
